Vertical Cantilever, Single Casing 200SV-SP Sump Slurry Pump

Structural features

 Vertical cantilevered, single casing structure.

 Double suction, open impeller design with carbide or rubber impeller.

 Cartridge bearing assembly, selecting high capacity bearing design.

 Adjustable clearance between impeller and backliner to ensure efficient pump operation.

 No need for any shaft seal.

 Pump and motor can choose direct coupled drive, belt drive.

 Wet-end Parts: Wear-resistant and corrosion-resistant high chromium alloy or rubber, polyurethane materials

 Pumping Medium: Abrasive and corrosive slurry containing solid particles

 Use: Immersed in the liquid, without any shaft seal and sealing water, suction insufficient working conditions can be used normally.

 200SV-SP(R) slurry pumps are widely used in mining, electric power, metallurgy, coal, building materials, chemical industry and other sectors
