HMC-800 Vehicle-mounted Coalbed Methane Multifunctional Drilling Rig

HMC-800 Truck-mounted Coal Bed Methane Drill Rig

Technical features:
1. The main engine adopts full hydraulic drive, automobile special chassis, strong passing ability, fast and convenient movement, and low transportation cost.
2. The drill boom adopts the double-speed mechanism of the mast jacking wire rope, which has a simple structure, shortens the transportation length, increases the working stroke, and the power head stroke reaches 15 meters, which is convenient for various process construction.
3. The power head adopts a tiltable structure with a maximum tilting angle of 85°, which is convenient for the withdrawal of the drill pipe.

4. The rotation of the drilling rig is driven by a low-speed and high-torque motor, with high operating efficiency, the maximum torque can reach 20 kN m, the maximum speed is 170 r/min, and the power head with different parameters can be configured according to the user's process requirements.
