AA/AA(R)

Product Introduction

AA(R) series is horizontal cantilever, single suction, centrifugal slurry pump. It is suitable

for mining, metallurgy, coal, electric power and other industrial sectors, conveying high concentration, strong abrasive slurry. This series of slurry pump can be used in single stage or in series. The slurry pump has a replaceable high hardness alloy or elastomer overcurrent lining to meet various erosive and corrrosive working conditions. Pump outlet direction can be rotated in 8 directions at an interval of 45° as required.

Product Features

Large diameter, short cantilever to ensure the rigidity of the shaft, suitable for high power conditions.

Hardened stainless steel shaft sleeve with "O" ring seals at both ends. The sliding shaft sleeve protects the shaft from wear and corrosion.

Ductile iron housing provides durability, strength, safety, and long service life.

Cartridge bearing assemblies allow maintenance in a clean environment without disassembling the pump, resulting in reliable operation and longer bearing life.

The wet end parts are made of high chrome alloy or rubber, which are wear-resistant, corrosion-resistant and impact-resistant, improving the service life. The metal wet end parts and rubber wet end parts can be interchanged or mixed to suit different working conditions.

The impeller adopts the structure of wide flow channel and concave shape of vane, which improves the flow rate and abrasive erosion, and prolongs the service life.

The shaft seal can adopt packing seal, expeller seal and mechanical seal to adapt to different application.

The pump outlet orientation can be placed at 45° intervals as required and oriented in any of the 8 positions to suit the installation and application.

Application

Semi-autogenous mill discharge

Ball mill discharge

Rod mill discharge

Coarse sand

Coarse tailings

Heavy-duty medium

Dredging

Oil sand

Ore sand

Concentrated tailings

Coal mining

Flotation

Metal smelting
